3D RIG : CMT8000 [Discontinue]

3d rig

Stereoscopic 3D Rig

Key Features
- Manual Convergence Adjustment
- Manual Fine Tuning of Convergence
- Manual Convergence Adjustment (Toed-in Pair)
- Manual Adjust distance from center (One-way Movement of Interaxial Distance)
Wheelbase Fine manual adjustment (Two-way Moving Interaxal Distance)
Manual Adjust distance from center (Two-way Moving Interaxial Distance)
- Left / Right Fixed Movement along the camera axis (X , Z Axis)
- Removable/Adjustable Type Sunscreen Flaps (Anti-Halation)
- Anti-reflection lens (light curtain ring)
- ¼, 3/8 inch Multi Locking Hole Base Frame
- Detachable type camera quick shoes
- Linear Scaler
  • Specifications
Model Name
CMT-8000
Size
631 X 806 X 676
Camera Interval
Right: 0~60mm / Left: 0~60mm
Tilt/Rotary Angle

tilt knob control 3 °
Rotary 6 °
Weight
20kg
Material/Surface Treatment
Aluminum, Stainless Steel /Anodizing
Color
Black
Accessories



3/8 inch bush Adaptor 2ea.
¼ screw 2ea
Quick Shoe 2ea.
Durable Travel Case(Option)
Camera Support
Sony EX3, HDC-P1 (QUICK SHOE 2EA)
Warranty
1 Year
